is a complete remote monitoring and control system for cathode
corrosion protection systems. The system integrates precision
control, automated testing, and remote monitoring into a single
industrial strength package.
The AnchorCP System provides a
Cathode Protection System with synchronized control of rectifiers.
Isolated analog inputs directly control rectifier on / off
cycles via relay outputs. The system provides for daily time
schedules with user selected times for on / off cycle scheduling.
The system clock is synchronized with a
highly accurate GPS antenna to provide rectifier interruption
and control of multiple units within +/- 2 millisecond accuracy.
The GPS interface allows for precise control over vast geographical
Local and remote electronic data recording
of system variables includes instant off and on / off cycle
readings, rectifier voltage, amperage and more. Over 100,000
data points can be stored in the unit.
AnchorView is easy to use
monitoring software that allows support personnel to view
and test the system local or remotely. No programming of the
system is required. Generates Excel “c.s.v.” data
and trend files for flexible report generation. It supports
direct connection to Access/SQL databases.
ModbusTCP and Modbus RTU protocol support provides ease of
integration to any SCADA System.
Status and alarm notification can be programmed
by the user to generate a message for events such as power
loss, structure-to-soil potential out of range, current out
of range, and more. Email, fax, and alphanumeric pager notification
Network and serial based communications
options provide simple enterprise integration. Wireless communications
options include cell, radio, and satellite. Dial and leased
line connections are supported.
Electrically isolated I/O channels provide
the capability to read and control any analog, digital, and
serial signals. Industrial NEMA standard enclosures are available
to meet the toughest environmental conditions. An optional
19” rack mount unit with visible status / alarm annunciation
is also available.
The cathode protection open system
design results in a cost-effective solution while offering
the user the option of customizing the system.
