AnchorFLOW-The AnchorFLOW flow computer is a complete gas flow measurement system.

AnchorFLOW provides a full function single to five run natural gas flow measurement computer function as an application within an IEC-61131-3 programming
environment.

Users can add PIDs or any custom control loops with IEC 61131-3 Ladder Logic or Structured Text Languages within a single industrial strength package.

Users select modes of operation via PC configuration screens that are easy to use, easy to verify. Isolated analog inputs directly feed FLOW calculations. The system provides for hourly and daily history with MMI connectivity via Modbus.

The Flow Computer open system design results in a cost-effective solution while offering the user the option of customizing the system.

Modbus Master capability and the custom control programmability of IEC 61131-3 provides for remote I/O as well as extensive control capability within the Flow computer system remote unit.

The system clock is synchronized with an on-board real-time clock that provides battery backup-up operation through extended power-off cycles. The user can remotely reset current system time.

Local and remote electronic data recording of system variables includes calculated flows as well as all critical inputs such as pressures, temperatures, mol percentage of gases, etc. for repeating local flow calculations.

AnchorFLOW provides ModbusTCP and ModbusRTU compatibility for ease of integration to any SCADA System.

AnchorFLOW is configured with the AnchorFLOWConfigTM PC based Windows® program. AnchorFLOWConfig is easy to use PC based software through which support personnel view, configure and test the system. No programming is required. AnchorFLOWConfig generates Excel® “csv” event log and history data for flexible report generation.

Status and alarm notification can be programmed by the user to generate a message for events such as power loss, input out of range condition, flow cut-off or out-of-range and more. Email, fax, and alphanumeric pager notification is available.

Internet and network based communications options provide simple enterprise integration. Wireless communications options include cell, radio, and satellite. Dial and leased line connections are supported.

Electrically isolated I/O channels provide the capability to read and control any analog, digital, and serial signals. Industrial NEMA standard enclosures are available to meet the toughest environmental conditions. An optional 19” rack mount unit with visible status/alarm annunciation is also available.


See Anchor FLOW Configurator Example.
